| 產品型號 | 適用尺寸 | 破斷拉力（kg） | 規格大小（mm） | 表 面 | 適合型號 | |||
| A | B | d | D | |||||
| SWH001 | 2" | 5000 | 53 | 85 | 40 | 9 | 鍍鋅 | LS01 |
| SWH002 | 1 1/2" | 3000 | 38 | 80 | 40 | 9 | 鍍鋅 | LS01 |
| SWH003 | 1" | 1500 | 28 | 60 | 20 | 5.5 | 鍍鋅 | LS01 |
| 產品型號 | 適用尺寸 | 破斷拉力(kg) | 規格大小(mm) | 表 面 | 適合型號 | |||
| D1 | D2 | D3 | H | |||||
| VSH001 | 1" | 1500 | 25 | 25 | 12 | 120 | 浸塑 | LS02 |
| VSH002 | 1" | 1000 | 22 | 23 | 12 | 95 | 浸塑 | LS02,LS03 |
| VSH003 | 1" | 1000 | 22 | 25 | 10 | 120 | 浸塑 | LS02 |
| VSH004 | 1" | 800 | 25 | 25 | 9 | 102 | 浸塑 | LS02 |
| 產品型號 | 適用尺寸 | 破斷拉力(kg) | 規格大小(mm) | 表 面 | 適合型號 | |||
| A | B | d | D | |||||
| VR001 | 4" | 20000 lbs | 102 | 88 | 20 | 18 | 鍍鋅 | LS01 |
| VR002 | 3" | 18000 lbs | 77 | 62 | 16 | 11.7 | 鍍鋅 | LS01 |
| VR003 | 2" | 5000 | 52 | 62 | 15 | 11.5 | 鍍鋅 | LS01 |
| VR004 | 1 1/2" | 3000 | 38 | 50 | 16 | 9.5 | 鍍鋅 | LS01 |
| 產品型號 | 適用尺寸 | 破斷拉力(kg) | 規格大小(mm) | 表 面 | 適合型號 | ||||
| A | B | C | d | D | |||||
| SJH001-01 | 2" | 5000 | 53 | 120 | 50 | 20 | 16 | 鍍鋅 | LS01 |
| SJH001-02 | 2" | 3000 | 52 | 123 | 50 | 20 | 12 | 鍍鋅 | LS01 |
| SJH002 | 1 1/2" | 3000 | 40 | 100 | 50 | 16 | 12 | 鍍鋅 | LS01 |
| 產品型號 | 適用尺寸 | 破斷拉力(kg) | 規格大小(mm) | 表 面 | 適合型號 | ||||
| A | B | C | D | E | |||||
| SNH002-01 | 2" | 2700 | 50 | 3 | 80 | 24 | 110 | 鍍鋅 | LS01 |
| SNH002-02 | 2" | 4500 | 51 | 5 | 120 | 25 | 153 | 鍍鋅 | LS01 |
| TSNH001 | 2" | 4500 | 51 | 6 | 118 | 25 | 118 | 鍍鋅 | LS01 |
| 產品型號 | 適用尺寸 | 破斷拉力(kg) | 規格大小(mm) | 表 面 | 適合型號 | ||||
| A | B | C | d | D | |||||
| WH001 | 4" | 10000 | 103 | 140 | 52 | 22 | 17 | 鍍鋅 | LS01 |
| WH002 | 3" | 10000 | 77 | 136 | 45 | 20 | 16 | 鍍鋅 | LS01 |
| WH003-01 | 2" | 5000 | 52 | 85 | 38 | 20 | 11.7 | 鍍鋅 | LS01 |
| WH003-02 | 2" | 5000 | 52 | 108 | 36 | 20 | 11.7 | 鍍鋅 | LS01 |
| WH003-04 | 2" | 4000 | 52 | 85 | 35 | 19 | 11 | 鍍鋅 | LS01 |
| WH003-05 | 2" | 3000 | 52 | 85 | 35 | 20 | 9.5 | 鍍鋅 | LS01 |
| WH003-06 | 2" | 680 | 52 | 72 | 30 | 25 | 6.5 | 鍍鋅 | LS01 |
| WH004-01 | 1 1/2" | 3000 | 38 | 65 | 30.5 | 17 | 9.5 | 鍍鋅 | LS01 |
| WH004-02 | 1 1/2" | 3000 | 38 | 86 | 35 | 18 | 9.5 | 鍍鋅 | LS01 |
| WH004-03 | 1 1/2" | 2000 | 38 | 65 | 30 | 18 | 8.5 | 鍍鋅 | LS01 |
| WH005-01 | 1 1/16" | 1500 | 28 | 58 | 28 | 17 | 7 | 鍍鋅 | LS01 |
| WH006 | 1 | 800 | 27 | 47 | 21 | 11 | 6.5 | 鍍鋅 | LS01 |
| 產品型號 | 適用尺寸 | 破斷拉力(kg) | 規格大小(mm) | 表 面 | 適合型號 | |||
| A | B | d | D | |||||
| UH001 | 3" | 10000 | 77 | 88 | 20 | 18 | 鍍鋅 | LS01 |
| UH002-01 | 2" | 5000 | 52 | 62 | 16 | 11.7 | 鍍鋅 | LS01 |
| UH002-02 | 2" | 4000 | 52 | 62 | 15 | 11.5 | 鍍鋅 | LS01 |
| UH003 | 1 1/2" | 3000 | 39 | 50 | 16 | 9.5 | 鍍鋅 | LS01 |
| UH004 | 1 1/16" | 1500 | 28 | 50 | 16 | 7 | 鍍鋅 | LS01 |
| 產品型號 | 自重(g) | 破斷拉力(kg) | 規格大小(mm) | 表 面 | 適合型號 | |||||||
| A | B | C | d1 | d2 | d3 | E | F | |||||
| EH001 | 320 | 5000 | 55 | 22 | 18 | 17 | 8 | 19 | 55 | 15 | 鍍鋅 | 轎車牽引帶 |
| EH002 | 240 | 3000 | 55 | 22 | 18 | 17 | 8 | 19 | 55 | 15 | 鍍鋅 | 轎車牽引帶 |
| 產品型號 | 適用尺寸 | 破斷拉力（kg） | 規格大小（mm） | 表 面 | 適合型號 | 備注 | |||||
| A | B | d | D | E | L | ||||||
| FH001-01 | 4" | 17000 | 70 | 95 | 6 | 17 | 45 | 93 | 鍍鋅 / 電泳鋅 | LS05,LS06 | 可鐵護卡分別有鐵或鋁 |
| FH002-01 | 2" | 10000 | 48 | 66 | 4.5 | 17 | 45 | 92 | 鍍鋅 / 電泳鋅 | LS05 | |
